Vortex VX5

VX5


The entry Vortex model is loaded with features and provides fast, fixed Recovery Speed on adjacent targets. Fully waterproof to 16 feet (5m). Single and Multi-Frequency options. Single-tier MD-MF Target ID scale. Three audio tones.

Lightweight and Collapsible!
Compacts to 24.75" (62.86 cm) and extends to 56.75" (144.14 cm)

Weight: 3 lbs. (1.38 kg) with coil cover installed.

MD-MF Technology Explained
The world’s first fully upgradeable waterproof detector series! As your skills increase, you can opt to convert your VX-5 to a VX-7 or VX-9 model with software updates. Each Vortex model upgrade includes additional operating frequencies, more advanced features, and more power!


FREQUENCY OPTIONS (2)
Choose a powerful single frequency (13 kHz) or search with Vortex’s simultaneous Multi-Frequency option to achieve excellent detection on all targets in all soils.
SEARCH MODE VERSATILITY




Choose from 4 options:

  • Zero Discrimination

  • Standard Mode (ideal for hunting relics, jewelry, and most international coins)

  • US Coins Mode

  • Custom Mode




SUBMERSIBLE TO 16 FEET (5 METERS)
Vortex waterproof up to 16 feet




Search streams, lakes, and the ocean coast with your Vortex.

(Submersible headphones available from Garrett)



Click to explore the Vortex VX5
Garrett Vortex VX5 control panel
+
+
+
+
+
+
+
+
+
+
+
+
+

World’s first fully transformable detector series!


As your skills increase, transform your VX5 into a VX7 or VX9.
Vortex Series Comparison Chart
Vortex VX5 Vortex VX7 Vortex VX9
Target ID Scale(s) One 0-99 Target ID 2-tier Target ID Scales 3-tier Target ID Scales
Frequencies Two: Multi-Frequency (Multi) and 13 kHz Four: Multi, 5 kHz, 13 kHz, Multi Salt Seven: Multi, Multi-Salt, 5 kHz, 9 kHz, 13 kHz, 18 kHz, 25 kHz
Search Modes Included Four: Zero, Standard, US Coins, Custom Five: Zero, Standard, US Coins, Beach, Custom Seven: Zero, Standard, US Coins, Thin Coins, Custom, Beach, Fast
Notch Discrimination Yes Yes Yes
High-Resolution Iron Discrimination Yes Yes Yes
Variable Recovery Speed No Yes: 2 settings Yes: 3 settings
Submersible to 16 feet (5m) 16 feet (5m) 16 feet (5m)
Z-Lynk Wireless enabled No Yes Yes
Increased sensitivity/depth No Yes Yes
Number of ID Tones 3 5 5
Iron Volume No Yes Yes
Pinpoint Mode Yes Yes Yes
Iron Audio Yes Yes Yes
Multi-Dimensional Multi-Freq. Yes Yes Yes
Ground Balance Yes Yes Yes
Frequency Shift (EMI reduction) Yes Yes Yes
Volume control Yes Yes Yes
LCD Backlight Yes Yes Yes
Detector Length 24.75" to 56.75" 24.75" to 56.75" 24.75" to 56.75"
Weight 2.9 lbs. without coil cover; 3.05 lbs. with cover installed 2.9 lbs. without coil cover; 3.05 lbs. with cover installed 2.9 lbs. without coil cover; 3.05 lbs. with cover installed
Standard Coil Included 8.5" x 11" DD Raider 8.5" x 11" DD Raider 8.5" x 11" DD Raider

Updateable / Upgradeable Yes Yes Yes


The detector series you can grow into.
Family using Vortex in the park
Vortex Searchcoils
Vortex searchcoils have a unique waterproof connector and are not compatible with other Garrett detectors.
Vortex Quick Start Guide
Vortex Quick Start Guide


Click to view or download a Vortex Quick Start Guide.

English
