Vortex VX9

N.º de pieza
1143060

VX9


MORE POWER THAN VX7

The Professional’s model. Full three-tiered MD-MF Target ID display (including two ferrous scales to help identify unwanted iron trash). Includes Multi-Salt and additional frequency choices. Additional Recovery Speed controls. FAST Mode for competition hunts and high-trash search areas. THIN COINS Mode for detecting fine, lower conductive coins such as hammered silver and thin gold coins.
Full Three-Tiered MD-MF Target ID Scale
When operating in Multi-Frequency, the VX9’s Target ID system displays a non-ferrous scale and two ferrous scales to help identify unwanted iron trash. Complex targets may indicate on both scales simultaneously.

More target information . . . so you can make better dig decisions!
Thin Coins Mode
Perfect setting made specifically for going after small thin coins - hammered silvers, tiny ancient gold coins, etc.




Faster recovery speed.

Enhanced Response on select Target ID range.

Target Response reduced for common ferrous items and high-tone targets.

Fast Mode
Designed for use in trashy areas, where abundant trash can mask adjacent coins. Also ideal for use in competition hunts. Includes fast recovery speed and reduced iron volume.
3 Levels of Recovery Speed control
Choose from three recovery speeds. Increased recovery/reactivity speed helps you more clearly distinguish adjacent targets. A great benefit for competition hunts and for hunt sites filled with metallic trash that might otherwise mask good targets.
Vortex searching beach
Includes Beach Mode and Multi-Frequency Salt operation!
Utilize the power of MD-MF Technology and Multi-Salt operation. Smooth operation and deep Target ID accuracy along wet salt beaches and in the surf. Fully submersible to 16 feet.
Wireless ready!
Built-in Z-Lynk wireless technology means you can search without cords attached to your detector.

Garrett MS-3 Z-Lynk headphones and other Z-Lynk accessories sold separately
SEVEN (7) FREQUENCY OPTIONS
Choose from five powerful single frequencies (5 kHz, 9 kHz, 13 kHz, 18 kHz, or 25 kHz) or search with one of two Vortex simultaneous Multi-Frequency options (the traditional Multi or Multi-Frequency Salt for saltwater beach use).
SEARCH MODE VERSATILITY


Choose from 7 options:

  • Thin Coins Mode

  • Fast Mode

  • Zero Discrimination

  • Beach Mode

  • Standard Mode (ideal for hunting relics, jewelry, and most international coins)

  • US Coins Mode

  • Custom Mode
  • Iron Volume
    Control What you Hear
    Iron Volume allows you to decrease the volume of ferrous (iron) targets, while the volume of non-ferrous targets remains at normal level. Experienced treasure hunters often like hearing all targets, but will appreciate the option to decrease the volume of undesired items. Eight adjustment levels.
    Lightweight and Collapsible!
    Compacts to 24.75" (62.86 cm) and extends to 56.75" (144.14 cm)

    Weight: 3 lbs. (1.38 kg) with coil cover installed.

    MD-MF Technology Explained
    The world’s first fully upgradeable waterproof detector series! As your skills increase, you can opt to convert your VX-5 to a VX-7 or VX-9 model with software updates. Each Vortex model upgrade includes additional operating frequencies, more advanced features, and more power!


    SUBMERSIBLE TO 16 FEET (5 METERS)




    Search streams, lakes, and the ocean coast with your Vortex.

    (Submersible headphones available from Garrett)



    EASY-ACCESS POWERFUL MENU OPTIONS
    Hi-Resolution Ground Balance
    175 points of ground balance resolution, ranging from ferrous ground to saltwater.

    Volume Control
    For both the built-in speaker and headphones.

    Eight Sensitivity/Depth Adjustments

    Iron Audio
    Garrett’s unique feature helps to correctly identify complex iron objects, such as bottlecaps and steel washers.

    Seven Search Modes + Pinpoint

    Frequency Shift
    Use to reduce noise or electrical interference (EMI)

    Backlight
    Illuminate your LCD screen to see target information at night.
    Click to explore the Vortex VX9
    Garrett Vortex VX9 control panel
    +
    +
    +
    +
    +
    +
    +
    +
    +
    +
    +
    +
    +
    +

    World’s first fully transformable detector series!


    As your skills increase, transform your VX7 into a VX9.
    Vortex Series Comparison Chart
    Vortex VX5 Vortex VX7 Vortex VX9
    Target ID Scale(s) One 0-99 Target ID 2-tier Target ID Scales 3-tier Target ID Scales
    Frequencies Two: Multi-Frequency (Multi) and 13 kHz Four: Multi, 5 kHz, 13 kHz, Multi Salt Seven: Multi, Multi-Salt, 5 kHz, 9 kHz, 13 kHz, 18 kHz, 25 kHz
    Search Modes Included Four: Zero, Standard, US Coins, Custom Five: Zero, Standard, US Coins, Beach, Custom Seven: Zero, Standard, US Coins, Thin Coins, Custom, Beach, Fast
    Notch Discrimination Yes Yes Yes
    High-Resolution Iron Discrimination Yes Yes Yes
    Variable Recovery Speed No Yes: 2 settings Yes: 3 settings
    Submersible to 16 feet (5m) 16 feet (5m) 16 feet (5m)
    Z-Lynk Wireless enabled No Yes Yes
    Increased sensitivity/depth No Yes Yes
    Number of ID Tones 3 5 5
    Iron Volume No Yes Yes
    Pinpoint Mode Yes Yes Yes
    Iron Audio Yes Yes Yes
    Multi-Dimensional Multi-Freq. Yes Yes Yes
    Ground Balance Yes Yes Yes
    Frequency Shift (EMI reduction) Yes Yes Yes
    Volume control Yes Yes Yes
    LCD Backlight Yes Yes Yes
    Detector Length 24.75" to 56.75" 24.75" to 56.75" 24.75" to 56.75"
    Weight 2.9 lbs. without coil cover; 3.05 lbs. with cover installed 2.9 lbs. without coil cover; 3.05 lbs. with cover installed 2.9 lbs. without coil cover; 3.05 lbs. with cover installed
    Standard Coil Included 8.5" x 11" DD Raider 8.5" x 11" DD Raider 8.5" x 11" DD Raider

    Updateable / Upgradeable Yes Yes Yes
    Vortex Searchcoils
    Vortex searchcoils have a unique waterproof connector and are not compatible with other Garrett detectors.
    Vortex Quick Start Guide


    Click to view or download a Vortex Quick Start Guide.
