VX7

MORE POWER THAN VX5

More advanced. Includes more frequency and mode options than VX5, including the powerful Multi-Frequency Salt mode for wet sand and saltwater surf use. Two-tiered MD-MF Target ID display (with separate ferrous and non-ferrous target scales). Additional audio tones plus adjustable Recovery Speed.

Includes Beach Mode and Multi-Frequency Salt operation!

Utilize the power of MD-MF Technology and Multi-Salt operation. Smooth operation and deep Target ID accuracy along wet salt beaches and in the surf. Fully submersible to 16 feet.

Recovery Speed control

Select from Standard or Fast speed. Increased recovery/reactivity speed helps you more clearly distinguish adjacent targets. A great benefit for competition hunts and for hunt sites filled with metallic trash that might otherwise mask good targets.

Dual Target ID Scale

When operating in Multi-Frequency, the VX7’s Target ID system displays both a ferrous target scale and a non-ferrous scale. Complex targets may indicate on both scales simultaneously. More target information . . . so you can make better dig decisions!

Wireless ready!

Built-in Z-Lynk wireless technology means you can search without cords attached to your detector.

Garrett MS-3 Z-Lynk headphones and other Z-Lynk accessories sold separately

Iron Volume
Control What you Hear

Iron Volume allows you to decrease the volume of ferrous (iron) targets, while the volume of non-ferrous targets remains at normal level. Experienced treasure hunters often like hearing all targets, but will appreciate the option to decrease the volume of undesired items. Eight adjustment levels.

Lightweight and Collapsible!

Compacts to 24.75" (62.86 cm) and extends to 56.75" (144.14 cm)

Weight: 3 lbs. (1.38 kg) with coil cover installed.

MD-MF Technology Explained

The world’s first fully upgradeable waterproof detector series! As your skills increase, you can opt to convert your VX-5 to a VX-7 or VX-9 model with software updates. Each Vortex model upgrade includes additional operating frequencies, more advanced features, and more power!

FOUR (4) FREQUENCY OPTIONS

Choose from two powerful single frequencies (5 kHz or 13 kHz) or search with one of two Vortex simultaneous Multi-Frequency options (the traditional Multi or Multi-Frequency Salt for saltwater beach use).

SEARCH MODE VERSATILITY

Choose from 5 options:

Zero Discrimination

Beach Mode

Standard Mode (ideal for hunting relics, jewelry, and most international coins)

USA Coins Mode

Custom Mode

SUBMERSIBLE TO 16 FEET (5 METERS)

Suba diver underwater scanning with a Garrett Vortex metal detector.

Search streams, lakes, and the ocean coast with your Vortex.

(Submersible headphones coming soon)

SEARCH WITH CONFIDENCE

Fast Target Recovery Speed (2 settings)

5-Tone Audible Target ID

Excellent Detection Depth and Target ID accuracy

Backlit LCD for night operation

Rechargeable Battery
Built-in lithium ion battery provides approximately 15 hours of search time per charge.

EASY-ACCESS POWERFUL MENU OPTIONS

Hi-Resolution Ground Balance
175 points of ground balance resolution, ranging from ferrous ground to saltwater.

Volume Control
For both the built-in speaker and headphones.

Eight Sensitivity/Depth Adjustments

Iron Audio
Garrett’s unique feature helps to correctly identify complex iron objects, such as bottlecaps and steel washers.

Five Search Modes + Pinpoint

Frequency Shift
Use to reduce noise or electrical interference (EMI)

Backlight
Illuminate your LCD screen to see target information at night.

Click to explore the Vortex VX7

World’s first fully transformable detector series!

As your skills increase, transform your VX7 into a VX9.

Vortex Series Comparison Chart

	Vortex VX5	Vortex VX7	Vortex VX9
MD-MF Target ID Scale	One Target ID Scale (0-99)	2-tier Target ID Scales	3-tier Target ID Scales
Frequencies	13 khz, Multi-Freq.	5, 13 kHz, Multi-Freq., Multi Salt	5, 9, 13, 18, 25 kHz, Multi-Freq., Multi-Salt
Search Modes	Zero, Standard, USA Coins, Custom	Zero, Standard, USA Coins, Beach, Custom	Zero, Standard, USA Coins, Thin Coins, Beach, Custom, Fast
Bottlecap Reject (MF function)	Fixed	Yes	Yes
Iron Boundary (MF function)	Fixed	Fixed	Yes
Notch Discrimination	Yes	Yes	Yes
High-Resolution Iron Discrimination	Yes	Yes	Yes
Sensitivity settings	8	8	8
Variable Recovery Speed	Fixed	Yes: 2 settings	Yes: 3 settings
Z-Lynk Wireless	No	Yes	Yes
Channel (EMI Reduction)	Yes	Yes	Yes
Increased sensitivity/depth	No	Yes	Yes
Auto Ground Balance	Yes	Yes	Yes
Number of Tones	3	3, 5	3, 5
Volume Control	Yes	Yes	Yes
Iron Audio™	Yes	Yes	Yes
Iron Volume	No	Yes	Yes
Button Lock (Dive Mode)	Yes	Yes	Yes
Pinpoint	Yes	Yes	Yes
LCD Backlight	Yes	Yes	Yes
Battery Condition Indicator	Yes	Yes	Yes
Length (Adjustable)	24.75" to 56.75" (62.86 cm - 144.14 cm)	24.75" to 56.75" (62.86 cm - 144.14 cm)	24.75" to 56.75" (62.86 cm - 144.14 cm)
Total Weight (with 8.5" x 11" coil)	3 lbs (1.38 kgs)	3 lbs (1.38 kgs)	3 lbs (1.38 kgs)
Fully Waterproof to	16 ft (5m)	16 ft (5m)	16 ft (5m)
Warranty	3 Years, Limited Parts/Labor	3 Years, Limited Parts/Labor	3 Years, Limited Parts/Labor

Updateable / Upgradeable	Yes	Yes	Yes
