1142860

VX5

The entry Vortex model is loaded with features and provides fast, fixed Recovery Speed on adjacent targets. Fully waterproof to 16 feet (5m). Single and Multi-Frequency options. Single-tier MD-MF Target ID scale. Three audio tones.

Lightweight and Collapsible!

Compacts to 24.75" (62.86 cm) and extends to 56.75" (144.14 cm)

Weight: 3 lbs. (1.38 kg) with coil cover installed.

MD-MF Technology Explained

The world’s first fully upgradeable waterproof detector series! As your skills increase, you can opt to convert your VX-5 to a VX-7 or VX-9 model with software updates. Each Vortex model upgrade includes additional operating frequencies, more advanced features, and more power!

FREQUENCY OPTIONS (2)

Choose a powerful single frequency (13 kHz) or search with Vortex’s simultaneous Multi-Frequency option to achieve excellent detection on all targets in all soils.

SEARCH MODE VERSATILITY

Choose from 4 options:

Zero Discrimination

Standard Mode (ideal for hunting relics, jewelry, and most international coins)

US Coins Mode

Custom Mode

SUBMERSIBLE TO 16 FEET (5 METERS)

Suba diver underwater scanning with a Garrett Vortex metal detector.

Search streams, lakes, and the ocean coast with your Vortex.

(Submersible headphones available from Garrett)

SEARCH WITH CONFIDENCE

Fast Target Recovery Speed

Excellent Detection Depth and Target ID accuracy

Backlit LCD for night operation

Rechargeable Battery
Built-in lithium ion battery provides approximately 15 hours of search time per charge.

Lightweight and Collapsible

3-Tone Audible Target ID

EASY-ACCESS POWERFUL MENU OPTIONS

Hi-Resolution Ground Balance
175 points of ground balance resolution, ranging from ferrous ground to saltwater.

Volume Control
For both the built-in speaker and headphones.

Eight Sensitivity/Depth Adjustments

Iron Audio
Garrett’s unique feature helps to correctly identify complex iron objects, such as bottlecaps and steel washers.

Four Search Modes + Pinpoint

Frequency Shift
Use to reduce noise or electrical interference (EMI)

Backlight
Illuminate your LCD screen to see target information at night.

Click to explore the Vortex VX5

World’s first fully transformable detector series!

As your skills increase, transform your VX5 into a VX7 or VX9.

Vortex Series Comparison Chart

	Vortex VX5	Vortex VX7	Vortex VX9
MD-MF Target ID Scale	One Target ID Scale (0-99)	2-tier Target ID Scales	3-tier Target ID Scales
Frequencies	13 khz, Multi-Freq.	5, 13 kHz, Multi-Freq., Multi Salt	5, 9, 13, 18, 25 kHz, Multi-Freq., Multi-Salt
Search Modes	Zero, Standard, USA Coins, Custom	Zero, Standard, USA Coins, Beach, Custom	Zero, Standard, USA Coins, Thin Coins, Beach, Custom, Fast
Bottlecap Reject (MF function)	Fixed	Yes	Yes
Iron Boundary (MF function)	Fixed	Fixed	Yes
Notch Discrimination	Yes	Yes	Yes
High-Resolution Iron Discrimination	Yes	Yes	Yes
Sensitivity settings	8	8	8
Variable Recovery Speed	Fixed	Yes: 2 settings	Yes: 3 settings
Z-Lynk Wireless	No	Yes	Yes
Channel (EMI Reduction)	Yes	Yes	Yes
Increased sensitivity/depth	No	Yes	Yes
Auto Ground Balance	Yes	Yes	Yes
Number of Tones	3	3, 5	3, 5
Volume Control	Yes	Yes	Yes
Iron Audio™	Yes	Yes	Yes
Iron Volume	No	Yes	Yes
Button Lock (Dive Mode)	Yes	Yes	Yes
Pinpoint	Yes	Yes	Yes
LCD Backlight	Yes	Yes	Yes
Battery Condition Indicator	Yes	Yes	Yes
Length (Adjustable)	24.75" to 56.75" (62.86 cm - 144.14 cm)	24.75" to 56.75" (62.86 cm - 144.14 cm)	24.75" to 56.75" (62.86 cm - 144.14 cm)
Total Weight (with 8.5" x 11" coil)	3 lbs (1.38 kgs)	3 lbs (1.38 kgs)	3 lbs (1.38 kgs)
Fully Waterproof to	16 ft (5m)	16 ft (5m)	16 ft (5m)
Warranty	3 Years, Limited Parts/Labor	3 Years, Limited Parts/Labor	3 Years, Limited Parts/Labor

Updateable / Upgradeable	Yes	Yes	Yes
