Garrett ATX Metal Detector

Garrett ATX Metal Detector

Hunt Once. Get It All. Find what other detectors have missed.
1140860 (ATX with 10" x 12" DD open coil)
1140870 (ATX with 11" x 13" DD closed coil)
1140880 (ATX with 11" x 13" Mono closed coil)

ATX Basic Packages Include:

  • Garrett MS-2 Headphones (waterproof headphones sold separately)
  • 10" x 12" Open coil cover
  • Garrett Detector Sling
  • Battery charger
  • AA alkaline and rechargeable batteries
  • Soft storage/travel case
  • Owner’s Manual


Garrett ATX DEEPSEEKER Package with 20" (50 cm) Deepseeker and 10"x12" DD open searchcoil (shown)
PN: 1140820

Garrett ATX DEEPSEEKER Package with 20" (50 cm) Deepseeker and 11"x13" DD closed searchcoil
PN: 1140830

Garrett ATX DEEPSEEKER Package with 20" (50 cm) Deepseeker and 11"x13" Mono closed searchcoil
PN: 1140840

ATX DEEPSEEKER Packages include:

  • 20" (50cm) Deepseeker mono coil
  • Garrett MS-2 Headphones (waterproof headphones sold separately)
  • Military-grade Garrett hard case
  • 15" x 20" Closed coil cover (shown attached to searchcoil)
  • 10" x 12" Open coil cover
  • Garrett Detector Sling
  • Battery charger
  • AA alkaline and rechargeable batteries
  • Soft storage/travel case
  • DVD and Manual

Accessory items are subject to change.
Click to Explore the ATX™
Find out more about key features and the technology behind the ATX™ by clicking on the buttons below.

High-End All-Terrain
Pulse Performance

Highly sensitive on tiny gold. Extends depth in the most extreme mineralized soils.

Maximum Detection
On All Targets
At The Same Time

No need to switch modes to enhance detection of one target while degrading another.

Ground Balance

Wide range to ground balance from saltwater to heavily mineralized ground (ironstone) without switching to special modes.
ATX Additional Features
True All Metal Mode
Detects all types of metal and provides the greatest possible detection depth and sensitivity.
All Terrain
Designed for use in wet, humid and dusty environments. Can be submerged in water to 10-foot (3m) depth.
Iron Check
Allows user to audibly identify iron targets when using a DD searchcoil.
Adjustable Threshold
User can manually adjust the audio threshold (the constant background “hum”) to better hear targets.
Fast Track Ground Balance
Automatic feature that allows the user to quickly ground balance the detector in mineralized soil conditions.
Ground Track (Automatic)
Detector continually measures ground mineralization and automatically adjusts itself for optimum performance. (Four track speeds on ATX.)
Electronic Pinpointing
This non-motion All-Metal Mode function is used to precisely locate a detected target’s position.
Three year warranty on limited parts and labor

Garrett detectors, pinpointers, and searchcoils now come with a 3 Year Warranty.

ATX Accessories
ATX Spanner Wrench
PN: 1625200  Price: $37.35
ATX Military Grade Hard Carry Case
PN: 1626500  Price: $209.94


Standard and optional searchcoils for Garrett’s detectors, and protective searchcoil covers.
Digging tools, treasure pouches, Keepers finds box, and sand scoops.
Garrett Z-Lynk wireless kits, headphones, and accessories.
Gear up for the field with Garrett daypacks and protective detector bags.
Standard use, fully submersible, and wireless headphone options.
Garrett branded shirts, caps, and informative treasure hunting books.


Sea Hunter Mark II
Overview Garrett’s highest performance PI technology. Provides maximum sensitivity on all targets all the time. Easy access to all controls with one hand. Includes advanced features to overcome the most extreme environmental conditions. Proven PI technology with 22 Frequencies. Ideal for saltwater hunting and wreck diving use.
Detection Performance Superior sensitivity on all targets, especially on small, low conductivity items (sub 0.1 gram nuggets, fine jewelry, etc.). Good detection on all targets from jewelry to coins to nuggets.
Ground Balance Capabilities YES. Fast Track NO
Balances to Saltwater YES. Inherently immuneto most saltwater; use Ground Balance if needed. NO. Inherently immune to most saltwater; use Discrim if necessary.
FastTrack Ground Balance YES NO
Continuous GroundTrack 4 settings: Off, Slow, Med, Fast NO
User Controls/Functions LED indicators show signal strength, current settings. Easy push-button control to alter Audio Threshold (25 settings), Volume, Sensitivity (13 settings), Pinpoint, etc. Control knobs to alter Audio Threshold, Discrimination. Sensitivity/Depth adjustment is fixed.
EMI Control Excellent immunity in more severe EMI environments. Has push-button automatic frequency scan and selection to provide quietest operation. Good immunity in moderate EMI environments. No frequency adjustment available.
Discrimination/Delay 25 settings, via push-button control Adjustable via control knob
Iron Audio YES (Requires DD coil) NO
Search Modes Motion and Non-Motion Modes, plus Pinpoint Two Trash Elim Modes (both Motion Modes)
Submersion Depth 10 feet (3m) 200 feet (65m)
Standard Searchcoil 10" x 12" DD 8" Mono
Length (Adjustable) 20" to 68" (.51m - 1.72m) 28" to 52" (.71m - 1.32m)
Power 8 AA alkaline, plus 8 AA rechargeables and charger 8 AA alkaline
Warranty 3 Year, Limited Parts/Labor 3 Year, Limited Parts/Labor
Headphones Included Standard land-use Submersible
Total Weight 6.9 lbs (3.13 kgs) 5.1 lbs (2.3 kgs) stem-mounted
